Three-Phase Gear Motor Forward & Reverse Wiring Diagram (220V/380V)

---

H1: Three-Phase Gear Motor Forward & Reverse Wiring Diagram (220V/380V)

H2: Understanding the 3-Wire Three-Phase Motor

This three-phase gear motor has three lead wires: Yellow, Blue, and White. All three wires must be connected to the power supply. Never leave any wire disconnected, or the motor will be damaged. The Blue and White wires control rotation direction by swapping their phase sequence.

H2: Forward Rotation Wiring Diagram

H3: Connection Steps

1. Connect Yellow wire to L1.

2. Connect Blue wire to L2.

3. Connect White wire to L3.

4. Power on. The motor runs in forward rotation.

H2: Reverse Rotation Wiring Diagram

H3: Connection Steps

1. Connect Yellow wire to L1.

2. Connect White wire to L2.

3. Connect Blue wire to L3.

4. Power on. The motor runs in reverse rotation.

Note: Only swap the Blue and White wires to change direction.
