F-Series F27-F157 Quick Selection Reference Table

---

The F series offers 11 machine base specifications for F27-F157, with power ranging from 0.12kW-200kW and torque ranging from 3N · m-22500N · m

机座号（frame size）	Adaptive power range	Allowable torque(Nm)	Output shaft diameter(mm)
F37	0.12 ~ 3 kW	180	25
F47	0.12 ~ 5.5 kW	360	35
F57	0.18 ~ 7.5 kW	420	35
F67	0.37 ~ 7.5 kW	700	40
F77	0.75 ~ 11 kW	1350	50
F87	1.5 ~ 22 kW	2500	60

F97	2.2 ~ 30 kW	3700	70
F107	3 ~ 45 kW	6500	90
F127	5.5 ~ 90 kW	10000	100
F157	11 ~ 160 kW	18000	120
