Technical parameters of R series reducer

---

The R series reducers/gearboxes provide a wide range of technical parameters to meet diverse industrial needs:

Power range: 0.12 kW -160 kW

Output torque: 1.4 N · m -23200 N · m

Output speed: 0.06-1090 r/min

Speed ratio range:

Basic type (R/RF): 3.33-289.74

Single stage (RX): 1.3-8.65

Combination type (R/R combination): up to 27001

Efficiency indicators: Level 2 96%/Level 3 94%/Combination type 85%

Whether in high torque heavy load or high-precision light load scenarios, the R series can provide matching transmission solutions.
