Micro AC Gear Motor Model Parameter Table: Power, Voltage, Frequency & Rated Speed

H1: Micro AC Gear Motor Model Parameter Table: Power, Voltage, Frequency & Rated Speed

H2: Complete Micro AC Gear Motor Parameter Table

The table below lists typical micro AC gear motor models from 6W to 370W. Rated output speed depends on the gear reduction ratio. All parameters can be customized for OEM projects.

Parameter Table of Micro Gear Motor

Model (Example)PowerVoltageFrequencyRated Speed (Output)
AC-6W6W1-phase 110V/220V50/60 Hz5–500 r/min
AC-10W10W1-phase 110V/220V50/60 Hz5–500 r/min
AC-15W15W1-phase 110V/220V50/60 Hz5–500 r/min
AC-20W20W1-phase 110V/220V50/60 Hz5–500 r/min
AC-25W25W1-phase 110V/220V50/60 Hz5–500 r/min
AC-30W30W1-phase 110V/220V50/60 Hz5–500 r/min
AC-40W40W1-phase 110V/220V50/60 Hz5–500 r/min
AC-60W60W1-phase 110V/220V50/60 Hz5–500 r/min
AC-90W90W1-phase 110V/220V / 3-phase 220V/380V50/60 Hz5–500 r/min
AC-120W120W1-phase 220V / 3-phase 220V/380V50/60 Hz5–500 r/min
AC-140W140W1-phase 220V / 3-phase 220V/380V50/60 Hz5–500 r/min
AC-180W180W3-phase 220V/380V50/60 Hz5–500 r/min
AC-200W200W3-phase 220V/380V50/60 Hz5–500 r/min
AC-250W250W3-phase 220V/380V50/60 Hz5–500 r/min
AC-370W370W3-phase 220V/380V50/60 Hz5–500 r/min
H3: Power

Available from 6W to 370W. Higher power delivers greater torque for heavier loads.

Do you need dimension drawings and 3D models, product catalogs, or customized scale quotations? Please fill in the required model, power, and installation type, and our engineers will reply to you within 24 hours.
