Quick Guide:NMRV63 gearbox output speed and torque complete comparison table

---

Complete comparison table of output speed and allowable torque corresponding to the full speed ratio of NMRV63 reducer, suitable for conventional 4-pole 1400rpm input motor:

Standard speed ratio	Output speed (rpm)	Rated allowable torque (N · m)
7.5	187	75
10	140	95
15	93	130
20	70	160
25	56	185
30	47	210
40	35	240
50	28	260
60	23	275

80	17.5	290
100	14	300

This parameter table is suitable for conventional 0.75kW-1.5kW matching motors and can be directly used for selection verification.
