JWM/JWB series screw jack/elevator accessories flange size
JWM/ JWBScrew Jack – Accessory Flange Dimensions & Mounting Drawings
The JWM/ JWB screw jack supports a variety of accessory flange options for motor mounting, load attachment, and system integration. This page provides complete flange dimension references for engineers and procurement professionals
Flange Mounting Options
JW series screw jacks support multiple flange configurations
| Flange Type | Description | Application |
|---|---|---|
| IEC Input Flange | Standard motor flange (B5/B14) | Direct motor coupling |
| NEMA Input Flange | US standard motor flange | NEMA motor integration |
| Servo Flange | Precision servo motor mounting | High-precision automation |
| Traveling Nut Flange | Flange on traveling nut (UR/DR types) | Load attachment on moving nut |
Huxing supplies worm screw elevators, bevel gear ball screw elevators, gear reducers, bevel gearboxes, and complete synchronous lifting system components.
Please inform us of your load, travel time, and speed, and arrange one-on-one technical consultation for you; Sending product catalogs or technical materials; Provide targeted solutions.
