How does the synchronous lifting platform screw jack system work?
The screw lift platform and jack lifting system are lifting components that are used in conjunction with two, four, six, or eight screw lifts. They have many functions such as lifting, lowering, pushing with auxiliary components, flipping, and adjusting various height positions
How It Works
A single motor drives all lifting points through a network of gear reducers, bevel gearboxes, and transmission shafts. As long as the shafts are turning, every screw jack moves in exact synchronism—without complex electronics or feedback loops
Key Advantages
1. High Load Capacity
A single screw jack handles over 50 tons, and multiple jacks work together to move loads exceeding 100
tons. Load capacity ranges from kilograms to several hundred tons.
2. Self-Locking Safety
Worm gear screw jacks remain in position after power loss. No additional brakes or locking mechanisms
are required—even for 200-ton loads
Screw Jack vs. Hydraulic – Quick Comparison
| Feature | Screw Jack System | Hydraulic System |
|---|---|---|
| Synchronization | Mechanical, absolute | Requires complex valves/controls |
| Self-locking | Yes (inherent) | No (requires external valves) |
| Cleanliness | No fluid leaks | Oil leakage risk |
| Maintenance | Low | High (fluid changes, seals) |
| Accuracy | ±0.1mm | Affected by pressure/temperature |
Scope of application
1. Execution devices such as lifting, displacement, clamping, and flipping in the production line;
2. Devices and clamping, lifting, and flipping devices in metallurgical equipment;
3. Hoists, flexible fixtures, and welding lifts in the vehicle manufacturing industry;
4. Lifting devices and solar power generation tracking devices for monocrystalline silicon and polycrystalline silicon ingot furnaces in the photovoltaic industry;
5. Remote control execution devices for aerospace, defense military, astronomical telescopes, etc;
6. Elevating stage lifting device;
7. Industries such as shipbuilding, water conservancy, papermaking, food and warehousing, and casting; Various actuators for medical equipment, woodworking machinery, and food machinery;
8. Lifting devices on machine tools such as vertical lathes and gantry cranes.
Need Help Selecting a System?
Send us your load, stroke, number of lifting points, and accuracy requirements – our engineering team will recommend the right configuration.
