What Motors Can Be Used with F Series Gearbox?
1、 Motor types compatible with F-series parallel axis gearboxes/F-series gearbox motors compatibility
The F series gearbox can almost adapt to mainstream industrial motor types on the market, which can be
divided into the following categories:
1. Classified by current type
电机类型（Motor type） 特点说明（Feature Description）
Three phase asynchronous motor The most commonly used in the industrial field, with a wide
power coverage ranging from 0.09kW to 200kW or even higher
Single phase asynchronous motor Suitable for situations with only single-phase power supply,
with relatively low power
2. Classified by special performance
电机类型（Motor type） 适用场景 （Applicable Scenarios）
防爆电机（ATEX） Hazardous environments with explosion-proof requirements such
as chemical, coal mining, dust, etc.
Variable Frequency Motor In situations where speed control is required, it should be used in
conjunction with a frequency converter
制动电机（Brake motor） Equipment that requires quick stopping or precise positioning, such
as lifting machinery
伺服电机（servo motor） Applications with high requirements for high-precision positioning
and dynamic response
高效电机（IE1/IE2/IE3） In situations that meet energy efficiency standards and have high
energy-saving requirements
双速电机（Dual speed motor） Equipment that requires switching between two fixed speeds
F-series gearboxes are usually equipped with IEC standardized motor flanges (B5 or B14), which can be
directly docked with the vast majority of motors on the market that comply with IEC standards
