40W 90mm Right Angle Gear Motor — 5IK40GN Series Specifications
H1:40W Right Angle Motor Reducer 40W 90mm Right Angle Gear Motor-5IK40GN Series Specifications Dimensional Drawing
The 5IK40GN uses the 90×90mm frame and pairs with the 5GN gearhead for higher torque capacity. At a 3:1 ratio, it delivers 0.63 N·m at 600 rpm, making it suitable for medium-duty conveyor and packaging drives.
| Parameter | Value |
|---|---|
| Output Power | 40W |
| Frame Size | 90×90mm |
| Voltage Options | 1PH 110V / 220V; 3PH 220V/380V |
| Gear Ratios | 5GN3K – 5GN200K (3:1 to 200:1) |
| Rated Torque (3:1) | 0.63 N·m / 5.5 lb-in |
| Rated Speed (3:1) | 600 rpm |
| Output Shaft | Keyway Φ12mm or Hollow Φ15mm |
| Insulation Class | Class B (130°C) |
| Protection | Built-in thermal protector |
| Safety Standards | UL, CSA, CCC, CE |
Configuration Options: Available as induction motor, reversible motor, or with electromagnetic brake.
Fan cooling and speed controller compatibility optional.
Do you need dimension drawings and 3D models, product catalogs, or customized scale quotations? Please fill in the required model, power, and installation type, and our engineers will reply to you within 24 hours
