CH / GH / GV Series Helical Gear Motor – Compact, Reliable, High-Torque Geared Motor for Industrial
The CH, GH, and GV、CV series helical gear motors are compact, high-efficiency geared motor solutions designed for a wide range of industrial drive applications. Built with hard-faced helical gearing, these gear reducers deliver low noise, high transmission efficiency, and exceptional reliability in continuous operation
Gear motor Key Specifications:
●Motor Power: 0.1kW – 4kW (100W – 3700W)
●Output Torque: Up to 1500N.m
●Output Speed: 6.9 – 460 RPM (50Hz)
●Reduction Ratios: 3:1 – 1800:1
●Gear Type: Hardened helical gears
●Housing Material: Aluminum alloy (100W–2200W) / Cast iron (larger frames)
●Protection Class: IP54 / IP55
Model Designation:
| Model | Mounting Type | Description |
| CH | Horizontal (Foot-mounted) | Standard horizontal gear motor |
| CV | Vertical (Flange-mounted) | Standard vertical gear motor |
| GH | Horizontal (Foot-mounted) | Heavy-duty horizontal series |
| GV | Vertical (Flange-mounted) | Heavy-duty vertical series |
| GHM / GVM | Flange input | Direct-coupled flange type |
| GHD / GVD | Double output shaft | Dual-shaft extension type |
Core advantages of gear motor:
●Hardened helical gear transmission - high load-bearing capacity, low noise, long service life
●Compact integrated design - saves space, is lightweight, and easy to integrate
●Multiple installation options - horizontal, vertical, foot mounted, flange mounted
●Optional electromagnetic brake - instant stop and hold capability
●Lifetime sealing - no oil leakage, minimal maintenance workload
Typical Applications:
Packaging machinery, conveying systems, food processing equipment, textile machinery, printing presses,
material handling equipment, automation lines, and general industrial drives.
📩 Request a Quote: Contact our engineering team for application-specific recommendations.
CH/CV/GH/GV vertical/horizontal gear reduction motor related knowledge: model description
