Brake AC Gear Motor – Electromagnetic Brake Micro Gear Motor 6W–90W
H1:Electromagnetic Brake AC Gear Motor – Instant Stop & Holding
H2: How It Works
The brake AC gear motor uses a DC90V electromagnetic brake. When power is cut, the brake engages instantly, stopping the load and holding it in position.
H2: Key Specifications
| Item | Value |
|---|---|
| Power | 6W – 90W |
| Brake voltage | DC90V |
| Ratio | 3:1 – 1800:1 |
| Shaft | 8–15mm |
| Mounting | Flange / foot |
Parameters of Micro AC Gear Motor:
| MOTOR FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm /120MM |
| MOTOR TYPE | Induction Motor / Reversible Motor / Torque Motor / Speed Control Motor |
| OUTPUT POWER | 6W / 15W / 25W / 40W / 60W / 90W / 120 W / 140W / 180W / 200W / 300W/400W(Can Be Customized) |
| OUTPUT SHAFT | 8mm / 10mm / 12mm / 15mm /18mm/22mm Round Shaft, D-Cut Shaft, Key-Way Shaft (Can Be Customized) |
| Voltage type | Single phase 100-240V 50/60Hz; Three phase 200-240V 50/60Hz; Three phase 440-480V 60Hz 4P |
| Accessories | Electric Brake / Fan / Speed Controller / Terminal Box / Thermal Protector |
| GEARBOX FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm /120mm |
| Gear Ratio | 3K-500K |
H3: Applications
Lifting and holding mechanisms
Inclined conveyors
Emergency stop systems
Packaging and medical equipment
Benefits
Instant stop, high holding torque, low noise, and long brake life.
📩 Request a Quote – Tell us your load and holding torque. We will recommend the right brake gear motor within 24 hours.
