90W 90mm Right Angle Gear Motor — 5IK90GN Series Selection Guide
H1:90W 90mm Right Angle Gear Motor -5IK90GN Dimensional Parameter Diagram
The 5IK90GN upgrades to a Φ15mm output shaft and supports 90W output. Both single-phase (1AC 220V) and three-phase (3AC 220V/380V) versions are available with IP54 protection and Class F insulation.
| Parameter | 5IK90GN-CF / 5GN7.5-640RS | 5IK90GN-SF / 5GN7.5-640RS |
|---|---|---|
| Power | 90W | 90W |
| Voltage | 1AC 220V | 3AC 220V/380V |
| Rated Speed | 1350 rpm | 1350 rpm |
| Gear Ratio | 7.5:1 – 640:1 | 7.5:1 – 640:1 |
| Output Shaft | Φ15mm solid | Φ15mm solid |
| Protection | IP54 | IP54 |
| Insulation | Class F | Class F |
