CH/CV/GH/GV gear motor purchase information
H2: Step 1 – Add Optional Features
| Option | When to Specify |
| Electromagnetic brake (DC90V) | Holding loads, inclined conveyors, lifts, emergency stop requirements |
| Double output shaft (CHD/CVD/GHD/GVD) | Driving two sides of a machine simultaneously |
| Flange input (CHM/CVM/GHM/GVM) | Flange input (CHM/CVM/GHM/GVM) |
| Manual brake release | Maintenance or manual positioning |
| Forced cooling fan | High ambient temperature or frequent start/stop |
H2: Selection Checklist – Before You Order
Use this checklist when requesting a quote:
1.Required output speed (RPM)
2.Required output torque (N.m) – calculated with safety margin
3.Motor power (kW) – or let us calculate it
4.Mounting orientation – Horizontal (CH/GH) or Vertical (CV/GV)
5.Shaft diameter required (18, 22, 28, 32, 40, or 50mm)
6.Reduction ratio – standard or custom
7.Voltage & frequency – e.g., 380V/50Hz, 3-phase
8.Brake required? Yes / No
9.Operating environment – temperature, dust, moisture□
10.Duty cycle – continuous, intermittent, or frequent start/stop
Q: What is the standard warranty for your medium gear reducer motors?
A: We provide 12-month full warranty for all non-human damage issues.
Q: Can I get a custom shaft size for my existing equipment?
A: Yes, we support non-standard shaft and mounting dimension customization.
Q: What is the typical lead time for standard models?
A: Most standard units are in stock and can be shipped within 3 working days.
Do you need dimension drawings and 3D models, product catalogs, or customized scale quotations? Please fill in the required model, power, and installation type, and our engineers will reply to you within 24 hours.
